Stainless Steel 316L Bars are composed of 16-18% Chromium, 10-14% Nickel, 2-3% Molybdenum, ≤0.03% Carbon, 2% Manganese, 1% Silicon, 0.045% Phosphorus, and 0.03% Sulfur, offering excellent corrosion resistance, high strength, and durability. Their mechanical properties include a tensile strength of 485 MPa, yield strength of 170 MPa, and elongation of 40%, ensuring strong structural performance. The physical properties consist of a density of 7.98 g/cm³, melting point of 1370°C, and thermal conductivity of 16.3 W/m·K, making these bars ideal for marine, chemical, and industrial applications.
| Specification | EN 10272, EN 10088-3 Grade 1.4404 |
|---|---|
| Standard | GB, UNS, AISI, SUS, API, ASME, ASTM, DIN, EN |
| Sizes | 3mm to 800mm diameter |
| Length |
|
| Finish | Centreless Ground, Bright, Rough Turned, Black, Peeled, Bright Drawn, Polished, Smooth Turned, Annealed, Grinding, Cold Drawn Turned |
| Tolerances | K10, H10, H11, H8, H13, K12, K9, K11, H12, H9 |
| Surface Finish | HL, BA, NO.4, 1D, 8K, 2D, NO.3, NO.1, 2B |
| Production Method | Rolled / Forged |
| Characteristics |
|
| Value Added Services at Suraj Metal |
|
| Other available forms | T-Bar, Rod, Profiles, Forging,. Blocks, Billet, Ingot, Angle, Rectangle, Half-Round, I/H, Rounds, Precision-Ground, Triangle, Threaded, Hollow, Channel |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
Excellent corrosion resistance and low carbon content, making them ideal for use in marine environments, chemical processing, and pharmaceutical industries. Their low carbon content improves weldability and reduces carbide precipitation.
Superior resistance to corrosion and excellent machinability. These bars are commonly used in architectural applications, chemical processing equipment, and marine environments where durability and a smooth finish are essential.
Excellent corrosion resistance and strength, suitable for use in marine, chemical processing, and medical applications. Their low carbon content enhances their resistance to localized corrosion and improves weldability.
Designed for applications requiring exceptional corrosion resistance and high strength. They are commonly used in the food processing, pharmaceutical, and marine industries, where reliability and resistance to harsh environments are crucial.
Excellent corrosion resistance and durability, making them suitable for use in chemical processing, marine applications, and manufacturing of precision components. Their low carbon content ensures enhanced weldability and resistance to pitting.
Used in environments where superior corrosion resistance and strength are required. Ideal for structural applications, chemical processing equipment, and marine components, these bars offer durability and performance with improved weldability.
Stainless steel 316L bars are widely used in applications requiring high corrosion and pit resistance, such as chemical processing, pharmaceuticals, marine environment, and food processing Because of the carbon content inside is smaller, so 316L offers better woldability and formability. It is commonly found in components for valves, pumps, heat exchangers and surgical instruments. The adhesive’s excellent durability makes it ideal for use in buildings, automotive parts and equipment lying in harsh environments, providing durability and reliability.
