Weston Stainless is a reputable manufacturer and supplier of stainless steel channels in the Midlands, UK. The company is well known for providing high-quality stainless steel products and serves a wide variety of industries such as construction, manufacturing, and infrastructure development. Their wide range of products includes different forms of stainless steel channels, including Parallel Flange Channels (PFC) UPE, UPA and UPN sections in standard materials like 304/1.4301, 304L/1.4307 316/1.4401 and 316L/1.4404. Applying cutting-edge laser fusion welding technology Weston Stainless also provides custom channel solutions to fit individual project needs, providing superior strength, durability and corrosion resistance for structural and architectural uses.
Stainless steel channels are iron-based structural elements containing at least 10.5% chromium and varying amounts of nickel, molybdenum and other metals to improve strength and corrosion resistance. The typical grades are 304 and 316, which are renowned for their high strength and resistance to chemicals and rust. These channels have high tensile strength, good ductility and high load-bearing capability, which makes them suitable for structural use in construction, marine and industrial applications. Their mechanical properties render them long-lasting and operational under stress, while their resistance to extreme temperatures and environmental conditions render them suitable for varied applications.
| Standard | ASTM A276, ASTM A479 / ASME SA276, ASME SA479 |
| Condition | HRAP |
| Size Range | Base: 80 to 150 mm Side: 40 to 75 mm |
| Thickness | 5 to 6 mm (depending on size) |
| Grades | 304, 316 |
| Processing | Bar cutting |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
Weston Stainless guarantees the provision of high-quality material, with all products subjected to strict testing such as hardness testing, spectrochemical analysis, PMI testing, tensile testing, micro and macro structural examination, pitting resistance, and IGC testing. Our commitment to quality is supported by detailed documentation like commercial invoices, packing lists with net and gross weights, box numbers, labels, and a Certificate of Origin signed by the Chamber of Commerce or respective Embassy. Further, a Third-Party Inspection Certificate ensures customer satisfaction with price and timely delivery of our stainless steel channels.
Choose the right stainless steel channel by considering load requirements, corrosion resistance, environment, grade (e.g., 304 or 316), size, and finish based on your structural or aesthetic application needs.
Grades like 310, 309, and 304H stainless steel are most suitable for high-temperature applications due to their excellent oxidation resistance, strength retention, and structural stability at elevated temperatures.
Yes, industries like power generation, petrochemical, aerospace, and furnace manufacturing commonly use stainless steel channels in high-temperature environments due to their heat resistance, durability, and corrosion protection.
Stainless steel channels can typically withstand temperatures up to 870°C (1600°F), with grades like 310 enduring even higher, around 1150°C (2100°F), while maintaining structural integrity and oxidation resistance.
Stainless steel channels find extensive application in various industries because of their durability, corrosion resistance and strength. In building construction, they ensure building, framework and bridge structures. In the shipbuilding and automobile industries, they are employed in chassis and structural supports. Stainless steel channels are also critical in producing food containers, pharmaceutical and chemical industries processing equipment because of their hygienic nature. They are also employed in architectural applications for decorative framing and trims. Their rust resistance makes them suitable for marine and outdoor conditions. Simple to fabricate and weld, stainless steel channels provide function and durability.
