Weston Stainless, a Midland, UK-based company, is a reliable source of top-quality stainless steel products, serving diverse industries with precision-fabricated materials. Of its products, SMO 254 Coils are a top recommendation for challenging uses. SMO 254 Coils are made from SMO 254, a high-alloy austenitic stainless steel that is renowned for its excellent corrosion resistance, particularly in chloride-bearing environments. In the form of strips and rolls, these coils provide superior strength, weldability, and durability. With a high molybdenum content, SMO 254 Coils find extensive application in marine, chemical, and desalination applications, providing long-lasting performance.
SMO 254 Coils consist of around 20% of chromium, 18% nickel, 6% molybdenum, 1% nitrogen, and low carbon content, which increases corrosion resistance. Mechanically, they provide tensile strength of around 650 MPa, yield strength of 300 MPa, and elongation of 35%, which results in superior durability and formability. Physical properties consist of a density of 8 g/cm³, thermal conductivity of 14.5 W/m·K, and a melting range of 1320-1390°C. These characteristics make SMO 254 Coils suitable for severe environments, with outstanding resistance to pitting, stress corrosion cracking, and high-temperature oxidation.
| Elements | Carbon | Chromium | Manganese | Molybdenum | Nickel | Nitrogen | Phosphorus | Silicon | Sulphur |
|---|---|---|---|---|---|---|---|---|---|
| SMO 254 UNS S31254 | 0.02 max | 19.5-20.5 | 1.0 max | 6.0-6.5 | 17.5-18.5 | 0.18-0.22 | 0.03 max | 0.8 max | 0.01 max |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Cb+Ta |
| SMO 254 Coils | 0.07 | 1.0 max | 1.0 max | 0.03 | 3.0 – 5.0 | Bal | 3.0 – 5.0 | 15.0 – 17.5 | 5 X C / 0.45 |
Contact us to get a quick quote for your requirement.
Superior corrosion resistance and strength, making them ideal for chemical, marine, and high-temperature applications. Their durability ensures reliability in extreme and aggressive environments.
High-performance stainless steel, known for outstanding corrosion resistance and strength. Ideal for harsh environments, they are used in chemical processing, marine, and high-temperature applications.
Excellent corrosion resistance and high strength. Ideal for demanding environments, they are used in chemical, marine, and high-temperature applications, ensuring durability and reliability.
SMO 254 Coils are widely utilized in high corrosion-resistant and strong industries. They find applications in marine environments as well, including seawater handling systems, ship construction, and offshore platforms because of their high resistance to chloride-induced corrosion. The chemical and petrochemical sectors use them in heat exchangers, tanks, and piping that is subjected to corrosive chemicals. They also find extensive use in desalination plants, pulp and paper treatment, food processing machinery, and pharmaceutical manufacturing. SMO 254 Coils are also used in power plants, systems for cleaning the flue gases, and protection equipment for the environment, lasting long and giving good performance.
SMO 254 Coils are provided with necessary test certificates like Mill Test Certificates (MTC) as per EN 10204 3.1, third-party inspection reports, and records of material traceability to guarantee quality and conformity. Packing is securely accomplished by wooden pallets, boxes, or water-resistance wrapping for protection during transit. Delivery is timely, serving worldwide markets through effective logistics, ensuring the item arrives with customers in perfect condition and as agreed within the specified time limit.
